Featuring a futuristic, robot-inspired design, this innovative AOV (Always-On Video) camera combines striking aesthetics with cutting-edge surveillance technology. Engineered for comprehensive security, it is equipped with a four-lens system that simultaneously displays four distinct video feeds, providing expansive, multi-angle coverage and eliminating blind spots. To ensure uninterrupted, 24/7 operation, the device is powered by a dual solar panel configuration that maximizes energy harvesting and significantly extends battery life. Perfectly suited for off-grid environments, this robotic-styled camera delivers continuous, reliable monitoring with an eco-friendly and autonomous power solution.
Why This Camera
This AOV 4-lens solar-powered camera stands out for its robotic design and multi-angle surveillance capability, combining futuristic aesthetics with high-performance monitoring.
Its four-lens system delivers simultaneous 4-screen output, ensuring no blind spots are left unmonitored — ideal for wide-area coverage without needing multiple devices.
The dual solar panel setup guarantees continuous 24/7 operation even in low-light or off-grid environments, making it perfect for remote or hard-to-wire locations.
Built with AI human detection and color night vision, it intelligently filters false alarms while delivering crisp, detailed footage day or night. Its rugged, weather-resistant build ensures durability in outdoor conditions, while PTZ functionality allows remote directional control for dynamic tracking.
Technical Specifications
| Imaging | |
| Image Sensor | 1/3" color CMOS |
|---|---|
| Resolution | 2MP + 2MP + 2MP + 2MP |
| Effective Pixels | 1920(H) x 2160(V) |
| Compression | H.264 / H.265 |
| Electronic Shutter | Auto 1/1.5s - 1/30000s |
| Min. Illumination | 0.01 Lux |
| S/N Ratio | 46dB |
| Scanning | Progressive |
| Lens & PTZ | |
| Lens Configuration | 4 lenses: 4mm + 4mm + 4mm + 4mm, fixed |
| Pixels | 8M Pixels |
| Pan Range | 0-355 degrees |
| Tilt Range | 0-90 degrees |
| Focus Control | Fixed |
| Night Vision | |
| IR LEDs | 24x infrared + 24x white light |
| IR Distance | 10m |
| IR Control | AGC auto control |
| IR Power On | Auto control |
| Day/Night | Color / B&W auto (IR-CUT) |
| Connectivity | |
| 4G band options | EU / Middle East / Africa edition: FDD-LTE B1/B3/B5/B7/B8/B20/B28 · TDD-LTE B38/B40/B41 (standard production). Americas edition: available on custom order, not held in stock — band list confirmed in writing per order. |
| WiFi | Version available (4G SIM and WiFi are separate versions, specify the destination market at order) |
| Protocols | TCP/IP, UDP, DHCP, MQTT, P2P |
| Main Stream | 1920 x 2160 @15fps |
| Sub Stream | 640 x 720 @15fps |
| Smart Features | |
| Detection | Motion detection + PIR human body infrared |
| Image Enhancement | BLC, 3DNR, WDR |
| Privacy Masking | Yes |
| Audio | Two-way audio (built-in mic & speaker) |
| Recording | MicroSD (up to 256GB) |
| Build & Power | |
| Housing | Plastic, IP66 |
| Bracket | Support |
| Power | DC 5V/1.5A or 7.5W+7.5W solar panel Battery(16000mAh) |
| Operation Temp | -30°C ~ +60°C |
| Storage Temperature | -30°C ~ +60°C, 0% ~ 90% RH (no condensation) |
| Reset Button | Yes |
| Packaging | |
| Unit Weight | 2.5kg |
| Box Size | 260 x 190 x 125mm |
| Outer Box | 525 x 415 x 510mm, 8pcs, 20kg |
| Mobile App | Hieasy (iOS / Android) |
Applications
Monitor expansive property boundaries, fences or gates with panoramic coverage from a single unit.
Oversee loading docks, storage yards or equipment zones with multi-angle views and AI-triggered alerts.
Secure farms, ranches or vineyards where power and internet infrastructure may be limited.
Track activity across sprawling sites with real-time multi-feed monitoring and solar autonomy.
Deploy in parks, parking lots or transit hubs for comprehensive surveillance with minimal maintenance.
Provide homeowners with full-property visibility and intelligent motion alerts via mobile app.
Planning a full deployment? See the scenario guides: warehouse and loading dock cameras and perimeter security cameras.
FAQ
Trial orders start small — talk to us about your volume. Logo printing, custom packaging and firmware defaults are available on OEM terms; we scale with you from first sample to full containers.
The four fixed lenses each capture a distinct view and stream simultaneously — four live feeds in one app screen, covering a wide area with no blind spots and no need for multiple cameras.
Yes — the dual 7.5W solar panel configuration maximizes energy harvesting into the 16000mAh battery, supporting continuous 24/7 operation even in low-light or off-grid locations.
The 4G SIM version connects via 4G LTE (FDD B1/B3/B5/B7/B8/B20/B28, TDD B38/B40/B41) with P2P cloud access — no WiFi or router required, ideal for remote sites. A WiFi version is also available where broadband is present; tell us the destination market and we will confirm the version and bands.
We manufacture as an OEM and do not hold finished CE or FCC test reports under our own name. What we do instead is support your own local approval: we supply the documents we actually hold, including detailed specifications, label artwork and wiring drawings, plus the battery paperwork your shipment needs. Tell us your destination market and what your authority asks for, and we will confirm in writing which documents ship with the order and which your side has to obtain locally.
Spare parts, firmware updates and warranty handling come from our own factory in Shenzhen. Your customers stay supported — and so does your reputation.
Hieasy (iOS / Android) is the companion app — free to download, with live view, playback, PIR push alerts, two-way talk and multi-user sharing. Pair by scanning the QR code on the camera.
