Home/Products/Solar Series/MO31
MO31 3-lens outdoor PTZ security camera — 6MP across three lenses
MO31 3-lens outdoor PTZ security camera — black-light full-color night vision
MO31 3-lens outdoor PTZ security camera — WiFi and 4G dual network
MO31 3-lens outdoor PTZ security camera — IP66 waterproof housing
MO31 3-lens outdoor PTZ security camera — three simultaneous views
Outdoor Series · Triple Coverage

MO31 3-Lens Outdoor PTZ Camera, 4G WiFi

Three lenses on mains power — each captures a different view simultaneously. Wide-angle, zoom and panoramic in one device, completely eliminating blind spots. 6MP total (2MP per lens), dual network, IP66 — the all-around coverage workhorse for yards, lots and facilities.

👁️ 3-Lens, 3-Channel — wide-angle, zoom and panoramic views at the same time. One device replaces three.
📸 2MP on each of the three lenses — every view at the same detail. Accurate colors by day, full-color night vision without glare.
📡 WiFi & 4G Dual Network — connect via WiFi or insert a 4G SIM. Free from wiring constraints.
🌧️ IP66 Waterproof — sealed housing for stable operation in heavy rain, dust and extreme temperatures.
🔊 Two-Way Audio & Mobile Control — real-time intercom, remote voice broadcasting and instant anomaly alerts.
OEM / ODM available Sample orders welcome Factory-direct since 2016

Why This Camera

Why This Camera.

Hub

An all-in-one intelligent security hub

This is not just a standard security camera — it is an all-in-one intelligent security hub. Three independent lenses work in sync to deliver simultaneous imaging, giving you the equivalent of a wide-angle sentry, a zoom hunter and a panoramic commander all in one unit. No need to stack multiple devices, saving you both costs and installation time.

Power

Stable 24/7, zero blind spots

The wired power design guarantees a stable 24/7 power supply, while the low-power chip ensures the device runs cool and stable without dropping offline, even during long-term operation. Whether you need to secure your home, protect a store, monitor a construction site, or oversee an orchard, this camera delivers all-around, high-definition, zero-blind-spot protection with the efficiency of one camera doing the work of three.

Technical Specifications

The full spec sheet.

Imaging
Image Sensor1/3" color CMOS Sensor
Resolution2MP + 2MP + 2MP
Effective Pixels1920(H)*2160(V)
CompressionH.264/H.265
Electronic Shutter TimeAuto(1/1.5s~1/30000s)
Minimun Illumination0.01 Lux
S/N Ratio46dB
Scanning SystemProgressive
Video OutputWireless network
Reset ButtonYES
PTZ
Horizontal Rotation Range0~355°
Tilt Rotation Range0~90°
Guard PointsNO
Optics
Focus Length4mm+4mm+4mm
Focus ControlFixed
Lens TypeFixed
Pixels6M Pixels
Night Vision
Infrared LED34PCS Infrared light +34PCS White light
Infrared Distance10M
IR StatusAGC auto control
IR Power OnAuto Control
Connectivity
RJ45NO
ProtocolTCP/IP, UDP/IP, DHCP, MQTT, P2P
ONVIFNO
P2PSupport
4G band optionsEU / Middle East / Africa edition: FDD-LTE B1/B3/B5/B7/B8/B20/B28 · TDD-LTE B38/B40/B41 (standard production). Americas edition: available on custom order, not held in stock — band list confirmed in writing per order.
WIFIVersion available (4G SIM and WiFi are separate versions, specify the destination market at order)
Main Stream1920×2160@15fps
Sub Stream640*720@15fps
Smart Phonesupport
Image & Smart Features
Day/NightColor/ B&W (IR-CUT )
Image ConfigYES
BLCSupport
3DNRSupport
WDRYES
Motion DetectionSupport
Privacy MaskingYES
Recording ModeSDcard
LanguageSimplified Chinese, English, Japanese, German, Russian, French, Italian, Spanish
Audio & Storage
Audio2-Way Audio (MIC and Speaker)
AlarmMotion Detection, PIR human body infrared detection
SD Card SlotSupport Max 256G
Build & Power
Housingplastic,IP66
BracketSupport
IR Cut FilterYES
PowerDC 12V/2A
Operation Temperature-30°C ~ +60°C
Storage Temperature-30°C ~ +60°C, 0% ~ 90% RH (no condensation)
Packaging
weight0.7KG
Box size262*215*195mm
Outer box size595*490*530MM
Weight of one box24KG(32PCS)
Mobile AppV380 Pro (iOS / Android)

Applications

Sites that need eyes everywhere.

🏭 Facilities with Mains Power

Where a supply exists, 24/7 recording without battery maths: three simultaneous views straight onto local storage.

🅿️ Parking & Vehicle Areas

Black-light full-color night vision records vehicle colour and detail without any visible IR glow.

🏪 Shopfronts & Forecourts

Cover the counter, the stock door and the forecourt together — one device replacing several fixed cameras.

🏡 Perimeters with Existing Wiring

Upgrade a wired boundary without pulling new cable: WiFi or 4G backhaul from the existing pole.

🌙 Night-Critical Sites

2MP per lens keeps identification range honest after dark — the figure that decides a claim.

Planning a full deployment? See the scenario guides: parking lot camera solutions and warehouse and loading dock cameras.

Install notes

Planning a mains-powered three-lens unit.

Plan the 12 V run, not the sun

There is no panel and no charge budget here — the constraint is getting DC 12 V / 2 A to the mount cleanly. Use a weatherproof junction at the drop, keep the adapter dry and out of standing water, and terminate the connector where it cannot be pulled.

The brightest night array of the three-lens line

Thirty-four infrared plus thirty-four white LEDs is a lot of light. Excellent for an active yard, genuinely unwelcome to a neighbouring bedroom or a passing driver — set the white-light schedule at commissioning rather than leaving it default.

Pick mains over solar where mains exists

Solar units cost more and need their panels aimed. Where a cable can realistically be run, this is the cheaper install and the steadier performer — keep the solar line for the points a cable genuinely cannot reach.

Light body, ordinary fixing

At 0.7 kg it suits wall, eave and standard bracket mounts without reinforcement. Housing is plastic, IP66, rated −20 °C to +60 °C.

Which model

MO31, MO32, MO23 or MS31?

You want a warning tone and two-way talk on site

MO32 keeps the three-lens format and trades part of its LED count for audible deterrence and a louder speaker — the one for gates and loading doors. See the full spec sheet.

A point needs only two views

MO23 drops to a 3 MP dual lens on the same V380 Pro app, usually enough for a doorway or a single bay at lower unit cost. See the full spec sheet.

The far point has no cable and no power

MS31 is the solar version of the same three-lens idea and runs the same app, so both live in one account on sites mixing powered and unpowered points. See the full spec sheet.

Ordering & shipping

Terms that decide the deal.

Samples and trial orders

Evaluation samples ship as 1–2 units so you can test on a real site. Trial orders up to 100 units carry their own price tier, and the sample charge is credited against your first bulk order rather than refunded in cash — first bulk orders start at 300 units.

Lead time

Standard-configuration orders ship in 7–14 days. OEM branding — logo, carton artwork and firmware defaults — adds time and is quoted against the specific job instead of assumed.

Payment and trade terms

Standard terms are T/T with 50% deposit and 50% before shipment. We quote FOB Shenzhen, or CIF to your port. Delivered-duty-paid is not something we sell — the customs entry stays in your name.

Warranty and spares

Twelve months, handled direct from our own factory in Shenzhen — spare parts, firmware updates and RMA replacements come from the people who built the unit.

Packing and freight

Ships in master cartons of 32 units, carton footprint 595*490*530MM, 24KG gross per carton. Give us your port and we will quote freight on CIF terms, or hand over on FOB Shenzhen if you run your own forwarder.

FAQ

What buyers usually ask.

What's the MOQ for OEM orders?

Trial orders start small — talk to us about your volume. Logo printing, custom packaging and firmware defaults are available on OEM terms; we scale with you from first sample to full containers.

Can I view all three lenses at the same time?

Yes — the app supports multi-view of all lenses in a split layout, plus full-screen on any single lens. Each PTZ lens also stores its own preset positions.

Does it need mains power, or can it run on battery?

This is a mains-powered model — that's what enables true 24/7 recording. For sites without power, our Solar Series covers the same multi-lens coverage off-grid.

What happens if WiFi fails?

The 4G SIM takes over automatically. Dual connectivity is the point: the camera stays reachable and keeps pushing alerts.

What is black-light night vision?

Black-light (or super-starlight) night vision uses a large-aperture low-illumination sensor plus invisible 940nm IR fill. It delivers full-color or near-color footage in near-total darkness without the visible red glow of conventional IR cameras — clearer evidence, zero giveaway.

What certifications are available?

We manufacture as an OEM and do not hold finished CE or FCC test reports under our own name. What we do instead is support your own local approval: we supply the documents we actually hold, including detailed specifications, label artwork and wiring drawings, plus the battery paperwork your shipment needs. Tell us your destination market and what your authority asks for, and we will confirm in writing which documents ship with the order and which your side has to obtain locally.

What about after-sales support?

Spare parts, firmware updates and warranty handling come from our own factory in Shenzhen. Your customers stay supported — and so does your reputation.

Which mobile app do the cameras use?

V380 Pro (iOS / Android) is the companion app — free to download, with live view, playback, PIR push alerts, two-way talk and multi-user sharing. Pair by scanning the QR code on the camera.

Does it keep recording if the mains drops?

No — this is a DC mains unit with no internal battery, so a power cut stops it. If ride-through matters at that point, the solar models are built for exactly that, and specifying one is better than adding a battery afterwards.

How far can I run the 12 V cable?

Not far on thin cable — voltage drop over distance is what kills these installations, and the symptom is a camera that reboots when the white LEDs switch on. Tell us the run length when you order and we will specify the lead and adapter to suit it.

Can I hand the site over in one app?

Yes, provided everything on it runs V380 Pro — MO31, MO32, MO23, MS31, MS32 and MSL31 included. Hieasy-family units need their own app, so if the site mixes both, plan a two-app handover or keep the fleet in one family.

What are the payment and delivery terms on the MO31?

Deposit and balance by T/T — 50% to start and 50% before shipment — quoted FOB Shenzhen or CIF to your port. Standard configurations ship in 7–14 days; OEM branding adds time and is quoted per job. Delivered-duty-paid terms are not offered.

Request a Quote

Get pricing on the MO31 4G/WiFi 3-Lens Camera.

Quantities, target market, customization needs — the more detail, the sharper the quote. Typical reply within 24 hours.

Your details are used only to respond to this inquiry.
